VRF System Air Conditioner
If you are seeking the most cost-effective solution for your next HVAC project, the VRF system air conditioner is a highly efficient and energy-saving option.
- Cooling/ Heating Capacity: 25.2KW-61.5KW
- Total Capacity: 50-130% of Outdoor unit capacity.
- Indoor Units Type: One-way Cassette, Two-way Cassette, 4-way Cassette, Round-flow cassette, Wall-mounted, Floor Ceiling, Short ducted, Medium ESP ducted, High ESP ducted, Fresh air processor
- Technology Feature: EVI Technology and Oil Balance Pipe Not Required.
- Applicable to various industries, including hotels, home use, manufacturing plants, and food & beverage factories.

VRF System Air Conditioner





If you are seeking the most cost-effective solution for your next HVAC project, the VRF system air conditioner is a highly efficient and energy-saving option
- Cooling/ Heating Capacity: 25.2KW-61.5KW
- Total Capacity: 50-130% of Outdoor unit capacity.
- Indoor Units Type: One-way Cassette, Two-way Cassette, 4-way Cassette, Round-flow cassette, Wall-mounted, Floor Ceiling, Short ducted, Medium ESP ducted, High ESP ducted, Fresh air processor
- Technology Feature: EVI Technology and Oil Balance Pipe Not Required.
- Applicable Industries: Hotels, Home Use, Manufacturing Plant, Food & Beverage Factory.
The characteristics of the multi-line system advantages:
- Energy saving, low operating costs, low noise;
- Small building space, easy to use, high reliability, no room, no water system, etc.;
- Advanced control, reliable operation, convenient maintenance;
- Good adaptability, wide refrigeration and heating temperature range;
- It has the advantages of convenient design and installation, flexible layout, not restricted by switching machine segment, flexible use time of each room;
- Long service life, unit failure rate is very low, basically self-regulation and diagnosis, do not need special maintenance, and outdoor unit service life of up to 30 years, thus greatly saving maintenance costs.
Product Advantages:
1.The total pipe length: 1000 m.
2.The longest pipe length: 200 /240m.
3.Height deference:Outdoor unit. Above<90m<90m.4.Outdoor unit below<110m.
5.Height difference between indoor units: 30m.
6.Length from first indoor distributor to last indoor unit 90 m.
7.Communication wire length of the VRF System Air Conditioner can be up to 1000m.
Specification
Model |
Diameter of Neck (mm) |
Height of Ventilator (mm) |
Diameter of Vent Head (mm) |
Height of Neck (mm) |
Base Flashing (mm) |
Number of Vanes |
Weight (KG) |
|||
AA | ||||||||||
300 | 300 | 440 | 460 | 190 | 500*500 | 2 | 2.1 | |||
500 | 500 | 460 | 700 | 190 | 700*800 | 2 | 4.3 | |||
700 | 700 | 725 | 980 | 290 | 1000*1000 | 3 | 9.4 |
